Sanitary Ball Valves (SBLV)


Three pieces heavy body full passage machined entirly from AISI 316L round bar for intercept fluids
and steam in pressure. Manual or with pneumatic actuator with proximity.




Cavity filled seat TFM 1600 PTFE
for high purity applications



Technical Data


BS Size range: 1/2" - 4"

DIN 11850 DN15 - DIN100

DIN 11851 3/8" - 4" & DN 25 - DN100

Connections: with clamp, butt-weld and threades connections.
Sanitary plus in DIN 11850 and DIN 11851 available.

Options:

manual or with pneumatic actuator with proximit
Surface finish: internal Ra ≤0.6µm external mirror polished
