The Quick Clean Relief Valve was designed for the stringent requirements of companies in sanitary
markets. This design virtually eliminates dead space in the valve where bacteria and germs can
contaminate the process.The Quick Clean Relief Valve can be sterilized with steam and germicide
and has Clean in Place (C.I.P.) capability. This valve can be disassembled for cleaning and
reassembled without changing the set pressure.
Safety First Valve, working with leading Biotech and Pharmaceutical companies, has developed the
standard relief valve for the sanitary market. This unique design allows for Clean in Place (CIP) with
the valve disc flush with the flat surface of the inlet. All machined surfaces meet or exceed 3A
Standards. The valve can be quickly and easily disassembled for sterilization and reassembled
without affecting the set pressure of the safety relief device. The Quick Clean Sanitary Relief Valve
is a soft seat modulating relief valve with set pressures from 1 psig to 2000psig.
Technical Data
Valve Pressure:1 psi to 2,000 psi
Combination units available
Available in ISO, DIN on request
Surface finish: internal Ra ≤0.6µm external mirror polished
